3.51 Lac / Piece
| Business Type | Manufacturer, Exporter, Supplier, Trader, Distributor, Importer |
| Motor Power | 20 HP |
| Compressor Type | Reciprocating Piston Air Compressor |
| Compressor Stage | Multi Stage |
| Click to view more | |
Product Details
Number Of Cylinders
3
Number Of Pistons
3
Free Air Delivery
50 CFM
Piston Displacement
41-49 CFM / 80 M³/hr
Maximum Working Pressure
70 Bar
Output Pressure
70 Bar
Cooling Method
Air Cooled
Mounting Type
Tank Mounted
Drive Type
V-Belt Drive
Lubrication Type
Splash Lubrication
Control System
Automatic Start-Stop Control (ASSC)
Valve Type
Concentric Ring Valve
Air Receiver Tank Capacity
300 / 500 Liter (Horizontal)
Power Supply
AC Three Phase
Motor Specification
IE2 Standard
Uses / Applications
High-pressure Industrial Use, PET Bottle Blowing, Pressure Testing, Gas Filling, Laboratory And Heavy Pneumatic Applications
